18K 4-Post Alignment Lifts

FPA18210, FPF18210

Hofmann’s 4-Post Alignment Lift offers 18,000 lbs. of lifting capability and a lifting system that provides for high-wear resistance and a smooth gliding operation. The 18K 4-Post Alignment Lift features 21 positions for maximum flexibility.

Click on one of the section titles to learn more about the 18K 4-Post Alignment Lift.

4-Post Lift Cable Safety Advisory

• Alignment level at 21 positions or flat runway version for multi-purpose vehicle servicing.
• Integrated air kit for optional Roller Jacks.
• 65" full-floating rear slip plates for longer wheelbase potential.
• Triple Safety System:
  • Safety locks in each column with single-point release.
  • Auto-engaging mechanical drop locks.
  • Velocity fuses on all hydraulically-operated components.
• Patented roll-formed front towers with Dura-Glide lifting system - integrates low-wear, Ultra-High Molecular-Weight polyethylene glide blocks to ensure long-term alignment accuracy.
• Built-in anti-sway system.
• Heavier 9/16" 6x37 pre-stressed cables for long life and added safety.
• 24" Pro-Style runways for wide-track vehicles and no runway adjustment.
• Hidden lifting cylinder under the runway adds accessibility and no vehicle door damage.
• Larger 8" cast iron pulleys and fiber-wound bushings for less wear and longer cable life.
• Multi-position nylon polyethylene slip plate cage with DelrinT bearings for improved wear and serviceability.
• Longer 52" approach ramps provide gentle drive-on angle for low-profile vehicles.
• Optional heavy-duty premium turntables increase alignment profitability.
• ALI/ETL/CSA Certified.

^† Non-alignment/flat runway/general service.
* Other Power Configurations Available.

Optional Accessories
